Choose the moisture-resistant core
Match the test method and result to the expected humidity. Green colour identifies a buying category; it does not establish moisture performance on its own.
MR MDF Manufacturer · Shuyang, China
Moisture Resistant MDF (Green MDF) for humid interiors.
Choose moisture resistant MDF, commonly called green MDF or green core MDF, for kitchens, bathroom furniture and humid-interior joinery. Our Shuyang factory supplies smooth boards, custom sizes and machining for your production.
- Board type
- Moisture-resistant MDF core
- For your production
- Painting · facing · machining
Technical specification
Moisture Resistant MDF Specifications
Moisture Resistant MDF, also called MR MDF, green MDF or green core MDF, is intended for protected humid interiors. Select the board using its moisture-performance data and the finished component design.
ThicknessCUZI MDF panel thickness range: 2–35 mm.
SizeCUZI MDF board formats: 1220 × 2440 mm; 2100 × 2800 mm; 1830 × 3660 mm; 1830 × 2440 mm; 2440 × 3660 mm; 1830 × 4200 mm.
DensityCUZI MDF density range: 2–4 mm: 800–810 kg/m³; 5–8 mm: 780–800 kg/m³; 9–11 mm: 760–780 kg/m³; 12–18 mm: 680–750 kg/m³; 19–35 mm: 650–680 kg/m³.
GlueThe bonding system follows the selected product grade and construction.
Formaldehyde gradeE0, E0.5 and E1 options. Tell us your destination and required test standard so we can help you choose the board and supporting reports.
SurfaceSanded and smooth; suitable for melamine pressing, painting and other downstream processes. Evaluate raw or faced options, cut edges, sealing and the complete finished construction against the required moisture performance and protected-interior end use.
Moisture resistanceMR MDF for protected humid interiors. The quoted grade and thickness are matched to the agreed moisture test, conditions, reported result and product-specific documents.
Thickness tolerance±0.1 mm nominal board thickness, with the measuring method agreed in the order. Finished-part tolerances follow the drawing.
Finish and processing
Core selection, finishing and moisture protection
Protect edges and openings
Seal cut edges, joints, holes and routed areas with the intended finish. MR MDF is not waterproof and needs protection from standing water.
Sheets or prepared components
Choose plain sanded boards or a decorative surface. Send drawings for cutting, drilling or CNC work, including the face, reverse and edge preparation.
Selection guide
Moisture data, edges and finished components
Read the Moisture Resistant MDF selection guide
Choose the board for the room and the component
Make the board choice part of your furniture design. A painted vanity front, a kitchen cabinet side and a supported shelf can share the same room while facing different humidity, cleaning and water-contact conditions. Describe where each part sits and how it is finished, then we can connect the MR board, machining and protection to that component.
Our moisture resistant MDF is intended for protected humid interiors. Elevated room humidity is different from standing water, a plumbing leak or continuous direct wetting. For furniture in a humid room, choose the MR grade and a complete protective finish. For shower-zone contact, immersion or repeated direct water contact, select a material and assembly designed for that exposure. The MDF water-exposure guide explains these different purchasing needs.
| Compare the same component | Raw / standard MDF | MR MDF | HMR MDF |
|---|---|---|---|
| Intended service | Protected dry interior | Protected humid interior with suitable finishing | Protected interior with a higher specified moisture-performance requirement |
| What identifies the board? | Actual grade, thickness and supplied condition | Actual MR grade, thickness and applicable data | Actual HMR construction, thickness and applicable data |
| What establishes moisture performance? | The data for that exact board | The matched method, conditions and reported result | The matched method, conditions and reported result |
| What completes the furniture? | Support, hardware, faces, reverse and edges | Support, hardware, protected faces, edges, holes and joints | Support, hardware, protected faces, edges, holes and joints |
Keep dimensions, support, hardware and finish the same when comparing Raw MDF, MR and High Moisture Resistant MDF. Then compare the offered board data and complete component price. HMR describes our higher moisture-performance option; its quotation and documents identify the actual construction and result. The MR and standard MDF guide helps prepare that comparison.
Select 18 mm MR MDF with the finished part in mind
18 mm moisture resistant MDF can be discussed for cabinet fronts, sides and supported furniture components. Choose it with the span, frame, fittings, routed depth and finish. A thickness choice gives your drawing a starting dimension; the finished component still needs its own support and hardware details.
The published 12–18 mm density band for our MR MDF is 680–750 kg/m³. Record the nominal density of the quoted board with its grade and 18 mm thickness. Density helps calculate weight and plan handling; the moisture-performance report describes a separate property. A higher density alone establishes an incomplete comparison of moisture resistance.
Our MDF range is 2–35 mm, with six listed full-sheet formats. We confirm each thickness/format combination and order quantity in the quotation, or work from your cut list. The nominal ±0.1 mm tolerance applies to board thickness, with the measuring method agreed. Finished component dimensions, holes and profiles follow the drawing's separately agreed tolerances. For decorative faces, add the complete finished-panel thickness and reverse construction.
For a kitchen cabinet, send the front or side drawing, hinge or connector layout, finish and any sink or appliance interface. For bathroom furniture, add the vanity location, plumbing openings, lower-edge clearance and cleaning routine. A sample machined and finished in the way your workshop uses gives you a useful reference for assembly and repeat orders.
Request moisture data for the actual grade and thickness
Ask for the MR board identity, nominal thickness, product data revision and relevant test report. Record the method and edition, specimen condition, exposure, reported result and agreed acceptance requirement together. The sample ID or product range in the document connects the data to the board in your quote.
European Panel Federation's property guide distinguishes thickness swelling under EN 317 from cyclic-moisture testing under EN 321. These tests address different conditions. A swelling result after a named immersion period and a result following cyclic treatment need their respective methods and conditions to be compared usefully.
| Grade and thickness to identify | Property and method to request | Conditions to record | Document and order connection |
|---|---|---|---|
| Offered MR board, including 18 mm when ordered | Thickness swelling; EN 317 if specified | Conditioning, immersion duration, water temperature and measurement points | Covered thickness, reported percentage, report/date and the agreed limit |
| Offered MR board and quoted thickness range | Cyclic moisture performance; EN 321 if required | Treatment cycles and the properties measured afterwards | Applicable results and the scope of the covered board |
| Offered MR board at receipt or processing | Moisture content; agreed method, such as EN 322 when specified | Sampling and conditioning, measuring method and timing | Record relevant to storage and workshop preparation |
| Offered core or complete faced construction | Destination-specific emission standard and test | Covered construction and the method's specimen conditions | Separate emission document for the proposed supply |
Thickness swelling is expressed as a percentage change from the initial thickness under the stated test. Board moisture content expresses water within the board; it is a different measurement. An E0, E0.5 or E1 designation concerns the specified emission requirement. Keep these items in separate rows of the order specification.
A small immersion test characterizes board response under its method; the furniture design also needs the intended service conditions and finished-component details. Include your acceptance requirement and destination with the document request. We confirm which current documents cover the proposed MR grade and thickness before the order is agreed.
Carry protection through faces, cut edges and openings
A finished face is one part of the protection plan. Machining creates new cut edges, routed surfaces and openings. Bring those details into the drawing, with the sealing, coating or edging to be completed by our factory, your workshop or the installer. Agree a compatible finishing system and follow its preparation and curing instructions.
| Furniture detail | Preparation and finish to agree | Check on a representative component |
|---|---|---|
| Broad face and reverse | Paint, decorative facing or another specified finish on the required sides | Coverage, appearance, adhesion and compatibility with the core |
| Straight cut edges and lower corners | Prepared edge with the agreed sealer/coating or edge band | Continuous finish, corner detail and finished dimensions |
| Routed profiles and grooves | Surface preparation and coating through the machined detail | Coverage at narrow areas and the remaining section |
| Hinge, connector and handle holes | Protection and fit compatible with the hardware | Required hole position, depth and assembly fit |
| Plumbing or sink-interface cut-outs | Finished exposed cuts, joints and installation sealing | Complete protection after the final cut and assembly |
| Joints and lower edges | Agreed joint detail, clearance and ventilation | Protection suited to the actual installed position |
A coating that works well on the broad face may need separate preparation on a machined edge. The EPF edge-finishing guide describes preparing and sealing cut edges before the finish is completed. Our edge-preparation guide helps you specify that workshop step.
Keep the finishing responsibility with every supplied condition. An unfinished MR board, a machined part and a fully finished furniture component reach different stages of preparation. Cutting or drilling after delivery can expose additional material; include its final protection in the workshop or installation plan.
Use the sample and documents together
Green MDF board is a familiar buying name for moisture-resistant MDF. Green colouring helps identify the board during handling; the MR formulation provides its moisture performance. Ask for the green-core or natural-colour option you need, and try a sample with your intended machining and finish. Compare green MDF and red MDF when choosing between moisture and fire requirements.
Use a representative part to try the tooling, edge preparation, coating and hardware. Keep the drawing revision, finish system, sample and agreed inspection points with the order. This helps your team repeat the same component preparation when the next boards arrive. For machining, our CNC MDF Processing page covers parts made to drawings; our bathroom vanity guide connects the material to the installed furniture.
MR MDF also benefits from dry handling. Keep boards supported flat in a covered, reasonably dry storage area, protected during transport and conditioned for the workshop before machining. The storage and conditioning guide explains how receipt condition and later environmental change affect preparation.
Bring a complete MR MDF request to our factory
Send the room and component, thickness, dimensions, quantities, finish and destination. Add the moisture test and acceptance requirement, product documents, hardware or part drawings, and which edges and openings need preparation before delivery. We can quote boards for your production or prepared components with the supplied condition clearly stated.
Our published MR MDF price range is US$190–300 per m³. The formal quote sets out the actual grade, dimensions, quantity, price and currency, processing, packing, FOB Qingdao or FOB Lianyungang, lead time, T/T or L/C conditions and validity. Normal production lead time is 3–10 days after the specification and commercial terms are confirmed; the schedule for further processing is included in the quote.
We reply within 12 hours. Samples are free and generally in stock, with courier cost paid by the buyer and creditable against a formal order. We confirm preparation, dispatch and estimated transit for your selected sample and address. Choose the sample you need to evaluate, and request its applicable product data at the same time.
Applications
Applications of Moisture Resistant MDF
MDF for Kitchen Cabinets
Order MDF sheets, decorative panels, routed doors and cut or machined cabinet parts from our Shuyang factory. Choose the faces, visible edges, hardware holes and packing groups for your cabinet range.
Explore applicationMDF for Bathroom Furniture
Order moisture-resistant boards, vanity fronts, side panels and machined cabinet parts from our Shuyang factory. Choose the supplied finish and edge work around your basin and plumbing layout, with MR or HMR MDF selected for each component’s exposure.
Explore applicationMDF for Cabinet Doors
Order slab fronts, routed doors and shaker-style MDF components from our Shuyang factory. Choose raw blanks, prepared fronts or the agreed finished construction, with profiles, hinge holes and left/right pairs matched to your door schedule.
Explore application
Boards and components
Moisture Resistant MDF photos and documents
Product documents for your order
Request thickness-swelling and strength data for the selected MR grade and thickness, with the test method and exposure conditions. Ask for emissions documents for your destination.
Made in Shuyang, China
From our factory to your workshop
Work with Shuyang Cuzi MDF Co., Limited on board selection, machining, inspection and export packing. Our factory has a total daily production capacity of 500 m³ across its operations.
Delivery, returns and warranty
- Delivery lead time
- 3–10 days
- Shipment
- By sea in containers
- Delivery terms
- FOB Qingdao / FOB Lianyungang, China
- Warranty
- 180 days
Made to order. The usual minimum is 1 × 20'GP per specification; mixed sizes or finishes are quoted together. Delivery lead time starts after specifications and terms are confirmed; sea transit is scheduled separately.
Freight is calculated for your ports and cargo quantity. Returns and exchanges, including timing and costs, are agreed in the order.
Delivery and freight terms · Returns and 180-day warranty · Packing and loading information
FOB China price
US$190–300 per m³
- Availability
- Available to order
Your quotation confirms the specification, quantity, packaging and final price.
Buyer FAQ
Your Moisture Resistant MDF questions, answered.
How should I specify 18 mm moisture resistant MDF?
State the MR grade, 18 mm nominal thickness, sheet or part dimensions, nominal density, finish, support and hardware drawing. The published 12–18 mm MR density band is 680–750 kg/m³. Request moisture-performance data covering the proposed grade and thickness, then agree machining, edge protection and the finished-component tolerances in your quote.
What is green MDF or green core MDF?
Green MDF and green core MDF are common names for moisture-resistant MDF used in kitchens, bathroom furniture and humid-interior joinery. Green colouring helps identify the board; its resin formulation provides the moisture resistance. Specify the MR grade, thickness and preferred core colour when ordering.
Is thickness swelling the same as moisture content?
Thickness swelling is the percentage change in thickness under a named test and exposure. Moisture content is the amount of water within the board under its measurement method. Keep both with their conditions when requested, and record the emission classification separately.
Is moisture resistant MDF waterproof?
MR MDF is designed for humid indoor use with suitable surface and edge protection. It remains a wood-based panel that can absorb water and swell during prolonged wetting. For standing water, immersion, repeated direct water contact or exterior exposure, choose a material specifically designed for those conditions.
Can MR MDF be used for kitchen cabinets and bathroom vanities?
It can be selected for protected cabinet doors, fronts, panels and storage components when the MR grade, finish and exposure suit the design. Pay particular attention to sink openings, plumbing cut-outs, joints and lower edges. Use a compatible protective finish, suitable ventilation and detailing that keeps standing water and leaks away from the furniture.
How do I compare MR MDF with HMR MDF?
Compare the actual boards, thicknesses, moisture test method and reported results. HMR MDF is offered for a higher specified moisture-performance requirement, with its own construction and technical information. Choose the product whose documented performance and finished-component design suit your room and exposure.
What moisture-performance and emission documents can I request?
Tell us the destination, intended use and required standard or method. We confirm the available technical data for the proposed board, including product identity, thickness, construction, moisture test method and reported result. E0, E0.5 or E1 requirements are recorded with their own emission standard and test method; we confirm the corresponding documents for your order.
Can I request a free MR MDF sample?
Yes. All product samples can be requested free of charge and are generally in stock. You pay the courier cost, which can be credited against a formal order. Send your thickness, finish and delivery address; we confirm availability, dispatch, courier cost and estimated transit time. Custom sample preparation is confirmed with the request.
Buyer guides
Practical guides for your MDF order.
MR MDF vs Standard MDF
Choose around your indoor humidity, component design, moisture-performance data, machining and finish.
Read guideIs MDF Waterproof?
Find the right material for humidity or water exposure, with practical guidance on faces, edges and finished components.
Read guideMDF Documents for Interior Projects: A Buyer Checklist
Plan MDF for interior projects with a practical checklist of products, drawings, samples and test reports, from material selection to ordering.
Read guideMDF Import Documents for EU Buyers: Emissions and Wood Traceability
Find the reports and paperwork for your EU MDF order. Start with the board and intended use, then bring product assessments, wood-source records and shipment documents into one purchasing file.
Read guideMDF Moisture Content: Storage and Conditioning for Production
Keep MDF ready for accurate cutting, finishing and assembly. Agree the moisture check, store panels on suitable supports and condition them for the production environment.
Read guideRed MDF vs Green MDF: Fire Retardant and Moisture Resistant Boards
Red MDF commonly identifies fire-retardant board, while green MDF commonly identifies moisture-resistant board. Choose by the job the panel needs to do, then match the grade, finish and dimensions.
Read guideLet's choose the right board for your room.
Tell us the furniture use, thickness, sizes, quantity and destination. We'll reply within 12 hours to help with a free sample, the relevant product information and a written quote.
