Painting, veneering and lamination
Use the smooth, unfinished face for your chosen finish. Prepare faces and seal cut or routed edges for the coating or adhesive system; check the result on a board sample.
Raw MDF Manufacturer · Shuyang, China
Raw MDF for furniture and finishing.
Start with a smooth, uniform board. We manufacture 2–35 mm raw MDF in Shuyang, China for furniture, painted panels and further processing, with board sizes and machining options to suit your production.
- Thickness options
- 2–35 mm.
- For your production
- Painting · veneering · machining
Technical specification
Raw MDF Specifications
Raw MDF, also called plain or unfinished MDF, is a factory-sanded wood fibreboard for painting, veneering, lamination and machining.
Thickness2–35 mm.
Size1220 × 2440 mm2100 × 2800 mm1830 × 3660 mm1830 × 2440 mm2440 × 3660 mm1830 × 4200 mm. Custom sizes by order.
Density2–4 mm: 800–810 kg/m³5–8 mm: 780–800 kg/m³9–11 mm: 760–780 kg/m³12–18 mm: 680–750 kg/m³19–35 mm: 650–680 kg/m³.
GlueThe bonding system follows the selected product grade and construction.
Formaldehyde gradeE0, E0.5 and E1 options. Specify your destination and required test standard; request the report for the selected board.
SurfacePlain, factory-sanded faces for painting, veneering or lamination.
Grade and intended useStandard grade for dry interiors; discuss MR or fire-rated MDF where your application requires it.
Thickness tolerance±0.1 mm nominal board thickness. Machined-part tolerances are agreed with your drawing.
Finish and processing
Painting, facing and CNC machining
Cut-to-size and CNC parts
Order full sheets or send drawings for cutting, drilling and routing. Include part quantities, hardware positions and the finished dimensions you need.
Dry interior use and storage
Standard Raw MDF suits dry interior furniture and panels. Store boards flat, dry and supported; choose a moisture-resistant grade for humid conditions.
Choose your board
Thickness, weight and cutting layout
Read the Raw MDF selection guide
New to MDF? Read how MDF is made and where it is used. For painted or machined furniture, compare MDF and plywood by strength, finish and use.
Choosing between board families? Compare MDF and HDF at equal dimensions, or review Hardboard, MDF and HDF for thin furniture parts. The specifications on this page describe the Raw MDF available for your order.
Select thickness for your component
Use the specification table above for the thickness and density ranges. Thin sheets suit supported backs and liners; thicker boards provide more material for shelves, fronts and routed profiles. Choose the grade with the component span, hardware, machining depth and finish.
For cabinet doors, send front and section drawings with hinge positions and the material remaining below grooves. For furniture components, include part sizes, quantities and support details. CNC MDF Processing and Routed MDF Cabinet Doors cover prepared components.
Calculate sheet weight and order volume
Volume in m³ = length × width × thickness, with dimensions in metres. Estimated board weight = volume × density in kg/m³. Packing is additional.
| Board at a calculation density of 700 kg/m³ | Volume per sheet | Estimated board weight |
|---|---|---|
| 1220 × 2440 × 12 mm | 0.0357216 m³ | 25.0 kg |
| 1220 × 2440 × 18 mm | 0.0535824 m³ | 37.5 kg |
For 100 sheets at 18 mm, the volume is 5.35824 m³. At the listed 680–750 kg/m³ density range, an 18 mm sheet weighs about 36.4–40.2 kg before packing. Use the sheet weight and CBM calculator for your dimensions, or read the MDF density guide.
Plan your cutting layout
The drawing below fits four 600 × 1200 mm parts into a 1220 × 2440 mm sheet, allowing 3 mm cutting kerf and a 5 mm edge reserve. At 18 mm thickness, finished-part volume totals 0.05184 m³; the full sheet is 0.0535824 m³.
For your quotation, we confirm whether the material charge uses finished-part volume or input sheets, plus the cutting, machining and packing required. Actual sheet dimensions and part tolerances determine the production layout. Send part IDs, quantities and any grain direction with your cut list. The board size guide explains how sheet format affects your yield.
Applications
Applications of Raw MDF
MDF for Cabinet Doors
Order slab fronts, routed doors and shaker-style MDF components from our Shuyang factory. Choose raw blanks, prepared fronts or the agreed finished construction, with profiles, hinge holes and left/right pairs matched to your door schedule.
Explore applicationMDF for Exhibition Displays
Painted panels, plinths and display modules, cut and labelled for transport and repeat assembly.
Explore applicationMDF for Acoustic Panel Substrates
Perforated, slotted or grooved substrates made to your drawings. Acoustic performance depends on the complete backing, cavity and installed system.
Explore applicationMDF Furniture Components
Furniture panels and shaped parts supplied as sheets or machined components, with part IDs and packing groups for assembly.
Explore application
Boards and components
Raw MDF photos and documents
Material report and board specifications
The 12 mm MDF report below covers the identified board. For another thickness or grade, request the matching specification and emissions documents.
Product report
12 mm MDF Material Report
View the material report for 12 mm MDF and ask our factory team for technical information for your order. Download the complete PDF to read the report information and results.
- Product
- 12 mm MDF
- Information
- Board dimensions and properties
- Report date
- 10 September 2026
- Document
- PDF · 1 page
Made in Shuyang, China
From our factory to your workshop
Work with Shuyang Cuzi MDF Co., Limited on board selection, machining, inspection and export packing. Our factory has a total daily production capacity of 500 m³ across its operations.
Delivery, returns and warranty
- Delivery lead time
- 3–10 days
- Shipment
- By sea in containers
- Delivery terms
- FOB Qingdao / FOB Lianyungang, China
- Warranty
- 180 days
Made to order. The usual minimum is 1 × 20'GP per specification; mixed sizes or finishes are quoted together. Delivery lead time starts after specifications and terms are confirmed; sea transit is scheduled separately.
Freight is calculated for your ports and cargo quantity. Returns and exchanges, including timing and costs, are agreed in the order.
Delivery and freight terms · Returns and 180-day warranty · Packing and loading information
FOB China price
US$138–260 per m³
- Availability
- Available to order
Your quotation confirms the specification, quantity, packaging and final price.
Buyer FAQ
Your Raw MDF questions, answered.
Can raw MDF be painted, veneered or laminated?
Yes. Prepare the factory-sanded faces and seal cut or routed edges for your chosen coating or adhesive. A sample lets you test the complete finishing process before ordering.
Which density applies to 12 mm and 18 mm Raw MDF?
Both fall within the 680–750 kg/m³ range. Specify the nominal density for your order alongside thickness, machining and intended finish. Density alone does not determine the suitability of a finished component.
How much does a 1220 × 2440 × 18 mm MDF sheet weigh?
At a calculation density of 700 kg/m³, the estimated weight is 37.5 kg. Across the listed 680–750 kg/m³ range it is about 36.4–40.2 kg, before packing. Use the weight calculator with your chosen board density.
Can you supply routed cabinet doors or cut-to-size parts?
Yes. Send front and section drawings, part quantities, groove depth and hardware positions. We confirm the material remaining after machining, supplied surface and finished-part tolerances with your quotation.
How are full sheets and machined components priced?
Full sheets are quoted with their nominal dimensions, sheet count and volume in m³. Component quotations state whether the material charge uses finished-part volume or input sheets, plus the agreed machining, finish and packing.
Can I get a Raw MDF sample?
Yes. Product samples are free; you pay the courier cost, which can be credited against a formal order. Send the thickness, intended finish and delivery address so we can confirm availability and dispatch timing.
Can standard Raw MDF be used in humid interiors?
Standard Raw MDF is intended for dry interior use. For humid rooms, discuss a moisture-resistant grade and the protection needed at faces, edges and joints. The full component and its exposure determine the material choice.
What documents can I request for my order?
The report on this page covers the identified 12 mm MDF. For your selected grade and thickness, request the board specification and emissions information for the destination and required test standard. Third-party inspection can be arranged before shipment.
